Product features

• ▪ 7-inch touch screen operation;

• ▪ Support multi language, convenient for different users;

• ▪ Built in environment automatic detection program, automatically detect the test environment and remind users;

• ▪ Programmable operation, realizing the setting function with one key;

• ▪ Built in international standard grade parameters, easy and fast operation;

• ▪ The highest pulse frequency is up to 1200khz;

• ▪ Rs232/usb interface, which can be controlled by PC and print test report.

Product parameters

• Product model


  Meet the standard


  Operation mode


  output voltage


  Pulse frequency


  Pulse polarity


  Running time


  internal resistance


  Midpulse front


  pulse width


  Output mode


  Coupling output


  Number in pulse


  Phase angle


  Pulse train period


  Coupling / decoupling network


  Working power supply


  ambient temperature

• EFT S6


  IEC61000-4-4、GB/T 17626.4


  7.0 inch full-color touch screen


  0.2~± 6KV


  1khz~1200khz ± 10%, continuously adjustable


  Positive, negative, positive before negative, negative before positive


  1 ~9999s, continuously adjustable


  50 Q±10%


  5ns ± 30%


  50ns ± 30% (50Q load) /35 ns ~150 ns (1kq load)


  IEC, customization, programming


  BNC, coupling decoupling network


  1 ~ 255, continuously adjustable


  0~360 ° synchronous or asynchronous


  0.15~99.9s, continuously adjustable


  Built in, single-phase three wire, 16A


  AC220V± 10% 50/60Hz


  15C~35°C
